Features
1. Plug and play
2. Metal casing, stable and durable
3. Transmission over single CAT6/6A/7
4. Highest resolution support 4Kx2K@60Hz
5. Support HDMI2.0, compatible with HDCP2.2
6. Support IR passback function (IR range support 20～60KHz )
7. Support distance up to 60m when 4K@30Hz, and 30m when
4K@60Hz
| Items | Specification |
| Voltage/Current | DC5V/1A |
| Power consumption | TX: 2.5W RX:＜3W |
| HDMI compliance | HDMI2.0 |
| HDCP compliance | HDCP2.2 |
| HDMI resolution |
480i@60Hz、480p@60Hz、576i@50Hz、 576p@50Hz、720p@50/60Hz、 1080i@50/60Hz、1080p@50/60Hz 4Kx2K 24/25/30/60/Hz |
| Supports audio formats | PCM |
| Maximum transfer rate | 10.2Gbps |
| Input and output TMDS signal | 0.5～1.5Vp-p(TMDS) |
| Input and output DDC signal | 5Vp-p(TTL) |
| Input cable length | ≤8m(AWG24) |
| Output cable length | ≤8m(AWG24) |
| Electrostatic protection of the whole machine |
1a Contact discharge level 3 1b Air discharge level 3 Implementation of the standard: IEC61000-4-2 |
| Working temperature | 0～50℃ |
| Storage temperature | -10～70℃ |
| Humidity (no condensation) | 0～90% |
| Dimension | 77.49(L) x 56.15(W) x 22.66(H)mm |
| Material | Aluminium alloy material + crystal panel |
| Treatment process | Grit blast |
| Color | Black |
| Weight | TX:80g, RX:80g |
| Mean time between failures (MTBF) | >30000 Hours |
