1. Uncompressed and zero latency.
2. Plug and play, without installation.
3. Resolution supported is up to 1080p@60Hz.
4. Transmission distance is up to 50meters via CAT6 cable.
5. Built in EDID pass back function to get better compatibility.
6. Include a transmitter unit (TX) and a receiver unit (RX), working as apair.
7. Support IR passback for remote control source device from receiver side easily.
| Item | Specification |
| HDMI signal | HDMI1.3, HDCP1.3 |
| Support resolutions | 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz |
| Network cable | Low resistance and consumption oxygen-free copper core（CAT6、CAT6A、CAT7） |
| Transmit distance | Full HD resolution 1080p@60Hz up to 50meters via CAT6 cable |
| Signal transmission | Uncompressed and zero latency |
| IR remote control | Support 20~60kHz wide frequency IR remote control |
| Working temperature | 0℃～60℃ |
| Power supply | 5V1A |
| Power consumption | TX<3W RX<3W |
| Material | Aluminium alloy |
| Product dimension | 71.6×66.6×24.8mm *2pcs |
| Weight | TX:70g RX: 70g |
| Color | Black |
