based or Over-IP)
auto-adjust RGB gain/delay control capability
down the KVM switch or PCs.
OSD (on screen display)
computers
| KSC-108E | Functions |
| 8 | Computer Connections |
| 1026 | Maximum Computer Connections |
| HDB 15 Female | Computer Connectors |
| 1 (One Local), plus1 Optional Modules: Selectable CAT5-Based or IP-Based Remote Console | Console Ports |
| RJ-45 Connector CAT5 console up to 1000 feet away from KVM switch with superior auto-adjust RGB gain/delay control capability | CAT5-Based Remote Console (DCC-100/DCC-100R) |
| RJ-45 8P8C for 10/100M Ethernet DB-9 pin male for Modem, Null modem and serial power Control Mini USB 2.0 receptacle | IP-Based Remote |
| Module (DIP-101) | |
| Daisy Chainable up to 8 levels | Daisy Chaining |
| Connector: DB15 (Female Type) | |
| On Screen Display (OSD), Hot Key, Push Button | Computer selection |
| Provide various Hotkey (Scroll-Lock/ Cap-Lock/ Num-Lock/ Alt/ Ctrl/ Win) | Hotkey |
| 1 | 7-seg LED for Bank and Port display |
| 5 ~ 99 Sec. | Auto-Scan Intervals |
| PS/2 | Keyboard / mouse Emulation |
| 2048 x 1536 | Video Resolution |
| (Local Console) | |
| 1600 x 1200 for CAT5-Based 500 feet remote console, | Video Resolution |
| 1024 x 768 for CAT5-Based 1000 feet remote console, | (Remote Console) |
| 1600 x 1200 for IP-Based remote console | |
| DC 12V, 1A | Power Adapter |
| DC 9V, 500mA | Power Adapter for CAT5 Remote Console Dongle |
| Metal | Housing |
| 19” Rack mount, 1U | Size |
| 2.2(Kg) | Weight |
| 448×190×44(mm) | Dimension (LX W X H) |
