HDMI – מפצלים, בוררים וממירים
מק"ט:14030145
- 1xS-video, 1x AV, 1x VGA, 3x HDMI audio and video signal inputs, converted to 1x HDMI output
- Support HDMI output up to 1080P/60Hz, the HDMI signal input support 3D HD source film (24fps)
- Support 30bit, 36bit deep color
- Support audio separation output, includes a fiber output and L&R analog output
- Supports 3 modes of EDID management for audio formats, can switch among built-in EDID (2CH/5.1CH) and external EDID (TV).
- PAL/NTSC automatic video format
- No loss of quality. Support input up to 15metres AWG26 HDMI standard cable length, output up to
- 20metres AWG26 cable length
- Easily switch between devices manually or with the IR remote control
- Plug and play
- Support 2x USB 1A current charging interface, and support charging for Apple device
- Built-in 4 ports 10/100M network switch, so easy to connect to the internet
- DC5V/2A power supply
- HDMI input Max resolution .....................up to 1080P/60Hz/ 3D(24fs)
- VGA input resolution..............................up to 1920 x 1080 @60Hz
- HDMI output resolution .....................up to 1080P/60Hz/ 3D(24fs)
- HDMI video color format ...........................24bit/deep color 30bit/36bit
- HDMI audio format..............DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
- HDMI Max bandwidth.................................225MHz
- HDMI Max baud rate.................................. 6.75Gbps
- Input/Output TMDS signal ..........................0.5~1.5Volts p-p（TTL）
- Input/Output DDC signal ..............................5Volts p-p (TTL)
- HDMI Input cable distance..................... ≤15m AWG26 HDMI standard cable
- Output cable distance .........................≤18m AWG26 HDMI standard cable
- Switch port number.................................4X RJ45
- MAC address........................................ 2K
- Network bandwidth..........................Auto-negotiation 10M/100M
- Network protocol......................IEEE 802.3, IEEE 802.3u, IEEE 802.3x
- Max working current...................................... 1A
- Power adapter format Input: ...................... AC 100V～240V 50HZ/60HZ; DC5V/3A
- Operating Temperature range............................-10 to +45℃
- Storage Temperature range...........................-20 to +60℃
- Operating Humidity range.....................10 to 90%RH (No Condensation)
- Storage Humidity range......................5 to 95%RH (No Condensation)
- Product size (L x W x H) ..........................280x170x40 (mm)
- Weight.........................................960g
